GENIE AERIAL WORK PLATFORMS — SUPER SERIES AWP25S
Genie® aerial work platforms are easy to use and cost effective, making them the first choice for a wide range of applications. One person can easily set them up and get to work within minutes, providing the ideal all-around tool for almost any access application. Their lightweight and compact size makes Genie aerial work platforms convenient to use in schools, churches, warehouses and more. Genie aerial work platforms also provide solutions for interior work on large construction sites, such as high rises, as well as being perfect for light-duty construction purposes.
The Genie® AWP®-25S Super Series aerial work platform can be used in a variety of rental, light-duty construction and maintenance applications. Its lightweight design makes it easy to load and transport in pickup trucks.
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
Specifications
- Sound And Vibration Levels - Sound Pressure level (platform workstation): < 70 dBA
- Technical Data - NOTE: *The metric equivalent of working height adds 2 m to platform height. U.S. adds 6 ft to platform height. **Gradeability applies to driving on slopes and may vary depending on options and machine configurations.
- Productivity - Platform Dimensions: (l/w/h) Gated narrow: 26/20/44.75 in (0.66/0.51/1.14 m)
- Productivity - Platform Dimensions: (l/w/h) Gated standard: 27/26/44.75 in (0.69/0.66/1.14 m)
- Sound And Vibration Levels - Sound Pressure level (ground workstation): < 70 dBA
- Productivity - Wall access front/side (Standard): 7 in/ 1 ft 5 in (0.18/0.43m)
- Technical Data - Height - tilted back** (Standard):
- Productivity - Platform Dimensions: (l/w/h) Standard: 27/26/44.75 in (0.69/0.66/1.14 m)
- Weight And Floor Loading**** - DC models : 817 lb (371 kg)
- Technical Data - Platform height: 24 ft 11 in (7.6 m)
- Technical Data - Length - tilted back**:
- Power - Power source - DC models: 12V DC
- Technical Data - Height - stowed (Standard): 6 ft 6 in (1.98 m)
- Sound And Vibration Levels - Vibrations: < 2.5m/s²
- Productivity - Corner access*** (Standard): 1 ft 7 in (0.48 m)
- Technical Data - Width : 2 ft 5 in (0.74 m)
- Technical Data - Working height maximum*: 30 ft 11 in (9.4 m)
- Technical Data - Length - stowed (Standard): 4 ft 3.5 in (1.31 m)
- Productivity - NOTE: ***Weight refers to standard configuration and may vary depending on options and/or country standards.
- Power - Power source - AC models: 110V/50-60 Hz | 220V/50-60 Hz
- Weight And Floor Loading**** - AC models : 727 lb (330 kg)
- Weight And Floor Loading**** - Occupied floor pressure: 0.28 psi (1.90 kPa)
- Productivity - Lift capacity: 350 lb (159 kg)
- Weight And Floor Loading**** - NOTE: ****Floor loading information is approximate and may vary depending on options and machine configurations. It should be used only with adequate safety factors.
- Productivity - Outrigger footprint (l/w) (Standard): 5 ft 9 in/ 5 ft 1 in (1.75/1.55m)
