Key Specs
- Maximum Lift Capacity: 10000 lb / 4535.92 kg
- Outriggers Up Max Lift Height: 43 ft / 13.11 m
- Maximum Lift Height: 43 ft / 13.11 m
- Maximum Reach: 30 ft 5 in. / 9.27 m
Key Features
- Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
- Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
- Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
- Increased versatility—wide range of attachment options
Specifications
- Speed - Maximum Telescope In: 13 sec.
- Transmission - Nr Forward Gears Standard: 4
- Machine Width: 8 ft 1 in. / 2.46 m
- Machine Length: 19 ft 9 in. / 6.02 m
- Service Brake Type: Wet Multi-Disc
- Function Pump Type: Load Sensing Piston
- Engine Model: QSF3.8L Tier 4 Final
- Transmission Type: Powershift
- Load Center: 2 ft / 0.61 m
- Lift Capacity at Max Reach: 2700 lb / 1224.70 kg
- Drawbar Pull: 24912 lb / 11299.89 kg
- Outside Turning Radius: 12 ft / 3.66 m
- Speed - Maximum Telescope Out: 15 sec.
- Capacity - Fuel Tank: 38.3 gal. / 144.98 L
- Maximum Lift Height: 43 ft / 13.11 m
- Maximum Engine RPM: 1500 rpm
- Machine Height: 8 ft 4 in. / 2.54 m
- Outriggers or Stabilizers: Yes
- Wheelbase: 11 ft 3 in. / 3.43 m
- Engine Horsepower: 110 hp / 82.06 kW
- Engine Manufacturer: Cummins
- Transmission - Nr Reverse Gears: 3
- Operating Vehicle Weight: 26235 lb / 11900 kg
- Ground Clearance: 1 ft 5 in. / 0.43 m
- Speed - Maximum Travel: 19 mph / 30.58 km/h
- Axle-Front: High Bias, Limited Slip
- Tire Size: 400/75-28
- Frame Leveling: 10 Degrees
- Speed - Maximum Lower: 9 sec.
- Axle-Rear: Planetary
- Maximum Lift Capacity: 10000 lb / 4535.92 kg
- Maximum Reach: 30 ft 5 in. / 9.27 m
- Lift Capacity at Full Height: 7000 lb / 3175.15 kg
- Outriggers Up Lift Capacity Full Reach: 1100 lb / 498.95 kg
