Forklifts

BENDI REAR WHEEL DRIVE NARROW AISLE DEEP REACH MULTIPURPOSE ELECTRIC FORKLIFTThe Bendi model B40AC-DR / B50AC-DR will stack loads two deep in aisles as narrow as *96” (2.4 M) has a basic starting capacity of 2,500 lbs. (1,136 kg) at 24” (600 mm) load center and has lift heights available to 35′ 5″ (10.80 M). The reach from face to mast is 52” (1,321 mm) and the integral pantograph reach stroke is 41” (1,041 mm) The B40AC-DR / B50AC-DR has a 33” (838 mm) wide tilting and side shifting fork carriage.
The Bendi B40AC-DR / B50AC-DR is a 4-wheel articulating forklift with dual independently driven rear-drive tires and soft-poly front load tires. The B40AC-DR / B50AC-DR can work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The B40AC-DR / B50AC-DR does all of the jobs of a reach and counterbalanced truck but in much narrower aisles.
EXCEPTIONAL PERFORMANCE AND MANEUVERABILITYEquipped with the Landoll DuraSteerTM front wheel hydraulic steering, the B40AC-DR / B50AC-DR provides exceptional control and makes load placement and retrieval superior to the competition.
3-STAGE MASTThe new mast has a rigid mounting and as standard a tilting and side shifting carriage. The new design offers increased mast rigidity, capacity and improved visibility. Dual free lift cylinders and optimized hose and chain routings have improved visibility thru the mast. Lowered heights have been reduced and a new mounting position on the 48” (1,219 mm) wide front axle reduces the distance from the face of the forks to the back of the axle thereby improving aisle performance. Mountings for cameras have been integrated into the inner mast and an optional integral side shifting fork positioner combination is also available.
*Based on 48” (1200mm) long x 40” (1000mm) wide load.

Bendi Rear Wheel Drive – Narrow Aisle Multipurpose High Lift Articulating Electric Forklift Maximizes Material Handling ProductivityThe Bendi model B40AC-HL/B50AC-HL works in aisles as narrow as 78″* (1.98M), has a basic starting capacity of 4,400 lbs. (1996 kg) at 24″ (600mm) load center and has lift heights available to 41′ (12.50M).
The Bendi B40AC-HL/B50AC-HL is a 4-wheel articulating forklift with dual independently driven rear-drive tires and soft-poly front load tires. The B40AC-HL / B50AC-HL can work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The B40AC-HL/B50AC-HL does all of the jobs of a reach and counterbalanced truck but in much narrower aisles.
Exceptional Performance and ManeuverabilityEquipped with the Landoll DuraSteerTM front wheel hydraulic steering, the B40AC-HL/B50AC-HL provides exceptional control and makes load placement and retrieval superior to the competition.
3-Stage MastThe new mast has a rigid mounting and as standard a tilting and side shifting carriage. The new design offers increased mast rigidity, capacity and improved visibility. Dual free lift cylinders and optimized hose and chain routings have improved visibility thru the mast. Lowered heights have been reduced and a new mounting position on the 42” (1067 mm) wide front axle reduces the distance from the face of the forks to the back of the axle thereby improving aisle performance. Mountings for cameras have been integrated into the inner mast and an optional integral side shifting fork positioner combination is also available.
*Based on 48” (1200mm) long x 40” (1000mm) wide load.

Bendi Rear Wheel Drive Narrow Aisle Multipurpose Electric ForkliftThe Bendi model B30AC/B40AC works in aisles as narrow as *78″ (1.98M), has a basic capacity starting at 3,000 lbs. (1361 kg) at 24″ (600mm) load center and has lift heights available to 26′ (7.92M).
The Bendi B30AC/B40AC is a 4-wheel articulating forklift with dual independently driven rear-drive tires and soft-poly front load tires. Excellent traction, braking and power enable climbing steep ramps with loads. Three or four stage masts are available making this unit excellent for loading/unloading trailers and containers. The B30AC/B40AC can also work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The Bendi B30AC/B40AC does all of the jobs of reach and counterbalanced trucks but in much narrower aisles.
Exceptional Performance and ManeuverabilityEquipped with the Landoll DuraSteerTM front wheel hydraulic steering, the B30AC/B40AC provides exceptional control and makes load placement and retrieval superior to the competition.
Maximizes Material Handling ProductivityThe versatile Bendi B30AC/B40AC forklift replaces conventional reach and counterbalanced fork trucks in standard warehouse operations. The unique design allows operators to use it as a counterbalance truck indoors or out, yet operates in narrow aisles in your warehouse, replacing reach trucks that require much wider aisles. The Bendi B30AC/B40AC has large diameter tires and the truck has great underclearance for avoiding floor obstructions. This forklift can go from inside the truck to the rack eliminating staging and additional operators and support forklifts.
*Based on 48” (1200 mm) long x 40” (1000 mm) wide load.

Bendi Rear Wheel Drive VNA Electric Warehouse ForkliftThe Bendi model B40VAC works in aisles as narrow as *72″ (1.8M), has a basic capacity of 4,000 lbs. (1814 kg) at 24″ (600mm) load center and has lift heights available to 30′ (9.14M). This high performance VNA Model has fast travel speeds and can climb steep ramps.
The Bendi B40VAC is a 4-wheel articulating forklift with dual independently driven rear-drive tires and soft-poly front load tires. Excellent traction, braking and power enable climbing steep ramps with loads. Three masts are available making this unit excellent for loading/unloading trailers and containers. The B40VAC can also work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The Bendi B40VAC does all of the jobs of reach and counterbalanced trucks but in much narrower aisles.
Exceptional Performance and ManeuverabilityEquipped with front wheel hydraulic steering, the B40VAC provides exceptional control and makes load placement and retrieval superior to the competition.
Maximizes Material Handling ProductivityThe versatile Bendi B40VAC forklift replaces conventional reach and counterbalanced fork trucks in standard warehouse operations. The unique design allows operators to use it as a counterbalance truck indoors or out, yet operates in very narrow aisles in your warehouse, replacing reach trucks that require much wider aisles. The Bendi B40VAC has large diameter tires and has great underclearance for avoiding floor obstructions. One forklift can go from the truck to the rack eliminating staging and additional operators and support forklifts.
*Based on 48” (1200mm) long x 40” (1000mm) wide load.
