Key Specs
- Platform Height: 31 ft 9 in. / 9.68 m
- Machine Width: 3 ft 10 in. / 1.17 m
Key Features
- Quieter, cleaner operation for a variety of environments
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Tight turning radius for great maneuverability
- Delivers 200% more battery life*
*Compared to a competitive model under similar test conditions. Actual results may vary.
Specifications
- Lower Time: 62 sec.
- Batteries: 4 x 6V, 220 amp-hr
- Working Height: 37 ft 9 in. / 11.51 m
- Maximum Lift Height: 31.8 ft / 9.68 m
- Lift Time: 55 sec.
- Hydraulic Pump: Fixed Displacement Gear
- Tire Size: 16 x 5 in
- Machine Weight: 4975 lb / 2256.62 kg
- Maximum Ground Bearing Pressure: 87 psi / 6.09 Kg/cm2
- Ground Clearance: 5 in. / 0.13 m
- Drive Speed - Platform Elevated: 0.5 mph / 0.80 km/h
- Wheelbase: 6 ft 10 in. / 2.08 m
- Platform Extension Length: 4 ft 2 in. / 1.27 m
- Turning Radius - Outside: 7 ft 11 in. / 2.42 m
- Platform Dimension A: 8 ft 3 in. / 2.5 m
- Machine Width: 3 ft 10 in. / 1.17 m
- Turning Radius - Inside: 0 in. / 0 m
- Machine Height - Rails Folded: 6 ft 6 in. / 1.97 m
- Platform Height - Lowered: 4 ft 2 in. / 1.26 m
- Brakes: Electric, Friction
- Platform Height: 31 ft 9 in. / 9.68 m
- Drive Speed - Platform Lowered: 2.5 mph / 4.02 km/h
- Platform Capacity - Extension: 250 lb / 113.40 kg
- Gradeability: 25 %
- Platform Capacity - Restricted: 1000 lb / 453.59 kg
- Charger: 20 amp automatic
- Capacity - Hydraulic Reservoir: 1.7 gal. / 6.44 L
- Platform Capacity - Unrestricted: 700 lb / 317.51 kg
- Platform Railing Height: 3 ft 7 in. / 1.1 m
- Platform Dimension B: 3 ft 8 in. / 1.12 m
- Machine Height: 7 ft 9 in. / 2.36 m
