Key Specs
- Platform Height: 26 ft / 7.92 m
- Machine Width: 3 ft 10 in. / 1.17 m
Key Features
- Quieter, cleaner operation for a variety of environments
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Tight turning radius for great maneuverability
- Delivers 200% more battery life*
*Compared to a competitive model under similar test conditions. Actual results may vary.
Specifications
- Drive Speed - Platform Elevated: 0.5 mph / 0.80 km/h
- Machine Height: 7 ft 9 in. / 2.36 m
- Wheelbase: 6 ft 10 in. / 2.08 m
- Machine Width: 3 ft 10 in. / 1.17 m
- Lift Time: 41 sec.
- Batteries: 4 x 6V, 220 amp-hr
- Platform Dimension B: 3 ft 8 in. / 1.12 m
- Brakes: Electric, Friction
- Lower Time: 50 sec.
- Machine Length: 8 ft 3 in. / 2.5 m
- Working Height: 32 ft / 9.75 m
- Platform Extension Length: 4 ft 2 in. / 1.27 m
- Maximum Lift Height: 26 ft / 7.92 m
- Platform Capacity - Extension: 250 lb / 113.40 kg
- Ground Clearance: 5 in. / 0.13 m
- Gradeability: 25 %
- Machine Weight: 4975 lb / 2256.62 kg
- Maximum Ground Bearing Pressure: 87 psi / 6.09 Kg/cm2
- Platform Height - Lowered: 4 ft 2 in. / 1.26 m
- Tire Size: 16 x 5 in
- Charger: 20 amp automatic
- Capacity - Hydraulic Reservoir: 1.7 gal. / 6.44 L
- Machine Height - Rails Folded: 6 ft 6 in. / 1.97 m
- Turning Radius - Inside: 0 ft / 0 m
- Platform Capacity - Unrestricted: 1000 lb / 453.59 kg
- Drive Speed - Platform Lowered: 2.5 mph / 4.02 km/h
- Turning Radius - Outside: 7 ft 11 in. / 2.42 m
- Hydraulic Pump: Fixed Displacement Gear
- Platform Railing Height: 3 ft 7 in. / 1.1 m
Alta Financial Services
Get in touch with our Financial Services department today.
View Financing Options- Tight turning radius for great maneuverability
- Delivers 200% more battery life* *Compared to a competitive model under similar test conditions. Actual results may vary.
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Quieter, cleaner operation for a variety of environments
