Key Specs
- Platform Height: 25 ft 6 in. / 7.77 m
- Machine Width: 2 ft 8 in. / 0.81 m
Key Features
- Quieter, cleaner operation for a variety of environments
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Narrow width fits through most standard doorways and tight aisles
- Delivers 200% more battery life*
*Compared to a competitive model under similar test conditions. Actual results may vary.
Specifications
- Platform Height - Lowered: 4 ft 1 in. / 1.23 m
- Brakes: Electric, Friction
- Charger: 20 amp automatic
- Platform Capacity - Extension: 250 lb / 113.40 kg
- Platform Dimension A: 2 ft 6 in. / 0.76 m
- Ground Clearance: 4 in. / 0.09 m
- Hydraulic Pump: Fixed Displacement Gear
- Platform Capacity - Restricted: 800 lb / 362.87 kg
- Turning Radius - Inside: 0 in. / 0 m
- Machine Height: 7 ft 8 in. / 2.33 m
- Drive System: 24V Electric
- Platform Railing Height: 3 ft 7 in. / 1.1 m
- Platform Extension Length: 3 ft / 0.9 m
- Platform Capacity - Unrestricted: 500 lb / 226.80 kg
- Maximum Ground Bearing Pressure: 90 psi / 6.30 Kg/cm2
- Turning Radius - Outside: 6 ft 9 in. / 2.06 m
- Gradeability: 25 %
- Machine Width: 2 ft 8 in. / 0.81 m
- Platform Height: 25 ft 6 in. / 7.77 m
- Platform Dimension B: 7 ft 7 in. / 2.3 m
- Lower Time: 37 sec.
- Wheelbase: 6 ft 2 in. / 1.88 m
- Tire Size: 16 X 5 in
- Working Height: 31 ft 6 in. / 9.6 m
- Capacity - Hydraulic Reservoir: 1.3 gal. / 4.73 L
- Batteries: 4 x 6V, 220 amp-hour
- Lift Time: 33 sec.
- Machine Height - Rails Folded: 6 ft 5 in. / 1.94 m
- Machine Weight: 4635 lb / 2102.40 kg
- Drive Speed - Platform Elevated: 0.5 mph / 0.80 km/h
- Drive Speed - Platform Lowered: 2.8 mph / 4.43 km/h
