Key Specs
- Platform Height: 20 ft / 6.1 m
- Machine Width: 2 ft 8 in. / 0.81 m
Key Features
- Quieter, cleaner operation for a variety of environments
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Narrow width fits through most standard doorways and tight aisles
- Delivers 200% more battery life*
*Compared to a competitive model under similar test conditions. Actual results may vary.
Specifications
- Platform Height - Lowered: 3 ft 8 in. / 1.1 m
- Wheelbase: 6 ft 2 in. / 1.88 m
- Platform Capacity - Unrestricted: 800 lb / 362.87 kg
- Lower Time: 40 sec.
- Platform Dimension A: 2 ft 6 in. / 0.76 m
- Platform Capacity - Extension: 250 lb / 113.40 kg
- Turning Radius - Inside: 0 in. / 0 m
- Tire Size: 16 X 5 in
- Platform Railing Height: 3 ft 7 in. / 1.1 m
- Turning Radius - Outside: 6 ft 9 in. / 2.06 m
- Machine Height - Rails Folded: 6 ft / 1.82 m
- Machine Height: 7 ft 3 in. / 2.2 m
- Hydraulic Pump: Fixed Displacement Gear
- Maximum Drive Height: 20 ft / 6.1 m
- Brakes: Electric, Friction
- Lift Time: 28 sec.
- Maximum Ground Bearing Pressure: 81 psi / 5.67 Kg/cm2
- Platform Extension Length: 3 ft / 0.9 m
- Drive Speed - Platform Lowered: 2.8 mph / 4.43 km/h
- Drive Speed - Platform Elevated: 0.5 mph / 0.80 km/h
- Platform Dimension B: 7 ft 7 in. / 2.3 m
- Machine Width: 2 ft 8 in. / 0.81 m
- Ground Clearance: 4 in. / 0.09 m
- Drive System: 24V Electric
- Machine Weight: 3610 lb / 1637.47 kg
- Capacity - Hydraulic Reservoir: 1.3 gal. / 4.73 L
- Gradeability: 25 %
- Charger: 20 amp automatic
- Batteries: 4 x 6V, 220 amp-hour
- Working Height: 26 ft / 7.92 m
