Key Specs
- Platform Height: 18 ft 9 in. / 5.72 m
- Machine Width: 2 ft 6 in. / 0.76 m
Key Features
- Quieter, cleaner operation for a variety of environments
- Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
- Narrow width fits through most standard doorways and tight aisles
- Delivers 200% more battery life*
*Compared to a competitive model under similar test conditions. Actual results may vary.
Specifications
- Platform Capacity - Extension: 250 lb / 113.40 kg
- Drive Speed - Platform Elevated: 0.5 mph / 0.80 km/h
- Tire Size: 12.5 x 4 in
- Lower Time: 30 sec.
- Drive System: 24V Electric
- Machine Weight: 2710 lb / 1229.24 kg
- Maximum Ground Bearing Pressure: 109 psi / 7.63 Kg/cm2
- Platform Capacity - Unrestricted: 500 lb / 226.80 kg
- Platform Railing Height: 3 ft 7 in. / 1.1 m
- Turning Radius - Outside: 5 ft 9 in. / 1.75 m
- Gradeability: 25 %
- Platform Dimension A: 2 ft 6 in. / 0.76 m
- Hydraulic Pump: Fixed Displacement Gear
- Ground Clearance: 4 in. / 0.09 m
- Lift Time: 26 sec.
- Platform Extension Length: 3 ft / 0.9 m
- Platform Dimension B: 6 ft 2 in. / 1.87 m
- Platform Height: 18 ft 9 in. / 5.72 m
- Machine Height: 6 ft 6 in. / 1.98 m
- Platform Height - Lowered: 2 ft 10 in. / 0.86 m
- Maximum Lift Height: 18.8 ft / 5.72 m
- Turning Radius - Inside: 0 in. / 0 m
- Charger: 20 amp automatic (120V/240V – 50/60Hz)
- Working Height: 24 ft 9 in. / 7.54 m
- Batteries: 4 x 6V, 220 amp-hour
- Brakes: Electric, Friction
- Wheelbase: 5 ft 3 in. / 1.6 m
- Capacity - Hydraulic Reservoir: 1.3 gal. / 4.73 L
- Drive Speed - Platform Lowered: 3 mph / 4.83 km/h
