COMBILIFT MULTI DIRECTIONAL FORKLIFT — COMBI-MR

COMBI-MR — THE AGILE MULTIDIRECTIONAL FORKLIFT THAT CAN OPERATE IN THE TIGHTEST SPACES

Combilift’s Multidirectional stand-on reach truck which offers superb maneuverability and safety in the tightest working conditions.

The multi-directional forklift designed for the safe, space saving and productive handling of long and bulky loads. Suitable for handling: Guided Aisles, Long Loads, Narrow Aisles and Palletized Goods.

Lithium Option Available

ELECTRIC – COMBI-MR Multi Directional Forklift

• Capacity: 2500 kg

• Platform Length: 790mm

• Overall Width: 1850 mm

• Engine Type Available: Electric

SPECIAL FEATURES

• Standing Operator Over-Head Guard

• Multi Directional Operation

• AC Electric Steering

• AC Motor Technology

• Multi-Function Joystick

• Optional Integrated Hydraulic Fork Position

• Stand and Sit-Down versions available.

SUITABLE INDUSTRIES

• Aluminum

• Building Materials

• Logistics

• Metals

• Plastics

• Steel

• Timber

• Warehousing

COMBI-MR

All models are highly customizable to suit your industry needs

ENGINE TYPE

COMBI-MR4 models are available in Electric power.

CAPACITY

The COMBI-MR4 range is capable of capacities of 5,000 -up to 10,000 Ibs

STORAGE

Utilizing the COMBI-MR4 advantages, means you can increase your storage by up to 50%.

MULTIDIRECTIONAL

Multidirectional operation allows for more versatility, improving efficiency and safety.

IMPROVED WORKFLOW

Designed to improve your workflow by effectively becoming three forklifts in one.

THE AGILE FORKLIFT

This compact truck features one rear wheel drive with a large rubber tyre and 360° steering rotation giving the Combi-MR the ability to drive across various surfaces. The Combi-MR features a cab that provides excellent ease of access aiding in quick and efficient picking by the driver.

The multi-functional controlled joystick allows the operator to smoothly change direction and travel speed, in addition to full control of all the hydraulic functions. This contributes to faster procedures for manufacturing distribution and logistics operations.

Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.

COMBI MR

Specifications

  • TECHNICAL DATA - Ramp Angle (degree): 15
  • TECHNICAL DATA - AC Rear Drive: 6 kW
  • TECHNICAL DATA - Track Front (mm): 1450
  • TECHNICAL DATA - Ground Clearance Under Mast (mm): 100
  • TECHNICAL DATA - Gradeability (%): 7
  • TECHNICAL DATA - Capacity (kg): 2500
  • TECHNICAL DATA - Approach Angle (degree): 35
  • TECHNICAL DATA - Max. (Mast Raised) (mm): Standard 4750 | Optional 6530
  • TECHNICAL DATA - Overhang Back (mm): 230
  • TECHNICAL DATA - Forward Tilt (degree): 2
  • TECHNICAL DATA - Platform Height (mm): 390
  • TECHNICAL DATA - Overall Width (mm): 1850
  • TECHNICAL DATA - Length from Face of Fork (mm): 1090
  • TECHNICAL DATA - Standard Color: Yellow and Gray
  • TECHNICAL DATA - Height Mast Closed (mm): Standard 2670 | Optional 2490
  • TECHNICAL DATA - Frame Opening (mm): 940
  • TECHNICAL DATA - Fork Sections (mm): 50 x 100 x 1150
  • TECHNICAL DATA - Battery (volts): 48V x 775Ah
  • TECHNICAL DATA - Platform Length (mm): 790
  • TECHNICAL DATA - Ground Clearance to Wheelbase (mm): 100
  • TECHNICAL DATA - Mast Travel (mm): 865
  • TECHNICAL DATA - Maximum Ground Speed (kmh): 7
  • TECHNICAL DATA - Overhang Front (mm): 200
  • TECHNICAL DATA - Unladen Weight (kg): 5000
  • TECHNICAL DATA - Freelift Height (mm): Standard 0 | Optional 1480
  • TECHNICAL DATA - Overall Length (mm): 1905
  • TECHNICAL DATA - Minimum Outside Radius (mm): 1955
  • TECHNICAL DATA - Backward Tilt (degree): 4
  • TECHNICAL DATA - Load Centre Distance (mm): 610
  • TECHNICAL DATA - Engine:
  • TECHNICAL DATA - Rear Tyre: Solid Rubber / OD 400mm / Width 180mm
  • TECHNICAL DATA - Standard Lift Height (mm): Standard 4040 | Optional 5540
  • TECHNICAL DATA - Front Tyre: Vulkollan / OD 250mm / Width 75mm
  • TECHNICAL DATA - Height Over Cab (without work lights) (mm): 2490
  • TECHNICAL DATA - Departure Angle (degree): 35
  • TECHNICAL DATA - Wheel Base (mm): Standard 1475 | Optional 1625
  • TECHNICAL DATA - Width over Forks (mm): 2105
